Part number: 170005-35
Structure: single chip, diaphragm spring, Pull‑type clutch.
Friction outside diameter: 430 mm(15.5 inches)
Maximum transmitted torque：2600 N·m
Mounting bolt hole: 12m 10 bolt hole, flywheel mounting surface.
Net weight of assembly: about 52-54 kg.
Separation form: pull type (separation bearing pulls diaphragm spring outward to separate, which is different from push type)
Specification of adapter driven plate: 430mm, 24 teeth spline, φ50.8 spline hole. Matching release bearing: pull-type 430 release bearing.
