Part Number: WP12.420E31
Cylinder configuration: in-line 6 cylinders
Displacement: 11.596L
Emission standard: National II/Euro II
Rated power: 309kW
Rated speed: 2200 r/min
Maximum horsepower: 420 horsepower
Maximum torque: 1750 N·m
Torque and speed range: 1300-1600rpm
Net weight of the whole machine: 900kg
Overall dimensions: 1566× 582× 1024 mm.
Cylinder diameter stroke: 126×155mm
